Magisk NetBird

English · 中文

Minimal Magisk module wrapper for the NetBird CLI daemon. Official NetBird binaries (currently v0.80.0) are bundled for three architectures.

DNS management is disabled by default when joining with netbird.service up.

Download

Latest release: https://github.com/ahsaboy/magisk-netbird/releases/latest

The release ZIP contains all three NetBird binaries and installs on arm64-v8a, 32-bit ARM, and x86_64. Magisk-compatible managers can check for updates from the module's update information. The ACTION button needs Magisk v28+.

Usage

Before reboot:

su -c '/data/adb/netbird/scripts/netbird.service up --setup-key <KEY> --management-url <URL>'
su -c '/data/adb/netbird/scripts/netbird.service status'

After reboot:

su -c 'netbird.service up --setup-key <KEY> --management-url <URL>'
su -c 'netbird.service status'
su -c 'netbird.service log'

To keep the setup key out of shell history and ps output, prefer a file:

su -c 'echo -n <KEY> > /data/adb/netbird/setup.key && chmod 600 /data/adb/netbird/setup.key'
su -c 'netbird.service up --setup-key-file /data/adb/netbird/setup.key --management-url <URL>'

Inspect every peer with connection details (P2P direct vs relayed, latency, traffic, last handshake):

su -c 'netbird.service peers'

In the Magisk app (v28+), or in a KernelSU/APatch manager, the module's ACTION button runs action.sh without arguments. It prompts for a volume key: Volume Up starts NetBird and Volume Down stops it. action.sh also accepts an explicit action for root-shell callers:

su -c '<module-dir>/action.sh status'
su -c '<module-dir>/action.sh refresh'
su -c '<module-dir>/action.sh start'
su -c '<module-dir>/action.sh stop'
su -c '<module-dir>/action.sh restart'
su -c '<module-dir>/action.sh peers'
su -c '<module-dir>/action.sh log'
su -c '<module-dir>/action.sh version'

Supported actions are status, refresh, start, stop, restart, route, peers, log, version, and help. Use the explicit status action when a non-interactive status refresh is needed. The log action prints the latest 200 lines and exits so that an ACTION page does not wait forever; use su -c 'netbird.service log' for continuous log following. Seeing daemon: stopped after stop is expected and does not indicate a failed stop. The same actions can also be invoked directly, for example su -c 'netbird.service peers'.

KernelSU users can open the module's WebUI for a mobile-first control panel. The page parses status JSON into connection cards and peer rows, and provides separate views for Peers, Networks/Routes, forwarding rules, health checks, versions, stored state items, and profiles. Network selection uses fixed networks select/deselect actions; selecting one route appends to the current selection. A 0.0.0.0/0 or ::/0 entry is an exit route supplied by the management service, while the exit peer itself is not selected by this module.

The WebUI does not accept setup keys or arbitrary shell commands. It does not start, stop, or restart the daemon; those lifecycle operations are handled by the module ACTION or boot service. It keeps raw log output out of the interface and focuses on parsed status, peer, route, health, profile, and state information. The top-right language selector supports Chinese and English, follows the system language on first launch, and persists the user's choice. Switching between Peers and Networks changes the view immediately; data refreshes silently with a five-second cooldown to avoid repeated root commands. The manager's ACTION button remains the short, no-argument refresh-and-status entry point.

Configuration

Defaults are set in netbird/settings.sh; override any of them via environment variables (environment outranks CLI flags in NetBird):

All of the variables above (and any other variable the official client supports) can be persisted in /data/adb/netbird/.env as KEY=VALUE lines (# starts a comment); a real environment variable still wins over the file. Start from the installed template:

cp /data/adb/netbird/netbird.env.example /data/adb/netbird/.env

Daemon-read variables (e.g. NB_LOG_LEVEL) apply after the next netbird.service restart; no reboot is needed. On Android builds without a usable IPv6 nat table, the module automatically enables NetBird's userspace firewall and userspace WireGuard so native ip6tables initialization cannot block startup.

Flags added by up persist in config.json and are applied on (re)connect, so after changing them run netbird.service down followed by netbird.service up (or netbird.service restart).

The status watcher re-applies both IPv4 and IPv6 Android root underlay rules every refresh cycle (default 60s), so Wi-Fi/cellular/SIM switches no longer require a manual restart. The same watcher probes daemon health each cycle and restarts it after 3 consecutive failed probes (watchdog: budget10 restarts, reset after5 healthy cycles - tunable via NB_WATCHDOG*, disable with NB_WATCHDOG=off). netbird.service stop (and uninstall) removes all ip rules and iptables rules the module added.

Dynamic status

While the daemon is running, module.prop is refreshed periodically. Because module descriptions are single-line metadata, status is shown as compact paired fields such as IP/peers, management/signal, relay/interface, memory, CA count, and refresh time. The peers field carries a direct/relay bracket ([P3 R1] = 3 direct, 1 relayed); WD=n shows accumulated watchdog restarts.

Custom CA trust

For self-hosted NetBird servers with a private CA, place PEM certificates in /data/adb/netbird/certs/ as .crt, .pem, or .cer files. /data/adb/netbird/ca.crt is also loaded automatically. Restart NetBird after changing certificates:

su -c 'netbird.service restart'
su -c '/data/adb/netbird/scripts/cert-trust.sh status'

The module injects /system/etc/resolv.conf for the Linux binary runtime. Android's normal app DNS is not changed by this; netbird.service up still disables NetBird DNS management with --disable-dns.

Direct NetBird commands should include the module daemon address:

su -c 'netbird --daemon-addr unix:///data/adb/netbird/run/netbird.sock status'
